Pneumatic Riveting Machine

Model : TC-141

TC-141 Pneumatic Riveting Machine

*  The main axis of the external pipe can be adjusted up and down. Easy operation and high accuracy.

*  For increasing the production capacity, the molds can be rapidly replaced. It's specially suitable for the working of versatile situation, lower quantity and in the assembly line.

*  The base of it is frame shaped, the center of it won’t be inclined while adjusting the height.

*  All types of voltage are available.

*  The longest solid rivet available is Ø7mm. The suggested and most economically efficient is the rivet below Ø6mm.





Specifications:

Model

TC-141

Motor

1/2HP

Stroke

40mm

Riveting capacity (mild steel)

Solid rivet 1-7, Hollow rivet 1-15

Working cycle time (sec)

0.5~12

Ordinary pressure (kg/cm2)

2-7

Max. output (kgf)

230~800

Distance between punch and table (mm)

150

Weigh (kg)

115

50/60HZ R.P.M.

1400/1720

------- Special machines for riveted products are available for ordering -------
